20+2m Wall Mounted Retractable Garden Hose Reel With Adjustable Nozzle
Description
Technical Parameters
Yongkang Fengding Industry & Trade Co., Ltd. is one of the leading manufacturers and suppliers of 20+2m wall mounted retractable garden hose reel with adjustable nozzle in China. With abundant experience, we warmly welcome you to buy premium 20+2m wall mounted retractable garden hose reel with adjustable nozzle made in China here from our factory. All customized products are with high quality and competitive price.
A Watering Set Designed as One Product
This reel is presented with a matching straight nozzle rather than as an empty hose-storage case. The grey-and-lime color scheme continues from the housing to the hose detailing and nozzle, giving retailers a coordinated garden-watering set that can be displayed and supplied as one SKU.
Pull, Pause and Return
The reference mechanism allows the hose to be extended and held at the required length during use. A further controlled pull releases the lock so the spring-driven system can guide the hose back into the enclosure. The user should keep hold of the hose while it retracts instead of allowing it to return freely.
Direct the Reel and Adjust the Nozzle
A wall bracket gives the reel a reference swivel range of 180 degrees, allowing the housing to follow the direction in which the hose is being used. At the working end, the ribbed straight nozzle is operated by rotation, moving from a light mist toward a concentrated stream and closing the flow when turned to its stop position.
Carry Point and Compact Housing
The top of the housing includes an integrated handle for lifting and handling the reel when it has been safely removed from its mounting position. The enclosed PP case stores the internal rewind system and keeps the hose arranged inside a compact wall-side unit.
Reference Performance for Product Selection
The proposed industry-standard configuration uses a 20 m outlet hose and a 2 m connection hose, both based on a 1/2-inch PVC garden-hose format. Reference pressure is 8 bar working and 24 bar burst, with an operating-temperature range of approximately -5°C to 45°C. Final ratings must be confirmed through the supplier's specification and sample testing.
Buyer Confirmation List
- Confirm 20 m outlet and 2 m inlet hose lengths
- Verify pressure, temperature and retraction test results
- Confirm tap adaptor and market-specific connector standard
- Check whether wall fixings and the adjustable nozzle are included
- Confirm MOQ, color options, branding and retail packaging
Reference values on this page are based on comparable 20 m automatic garden hose reels. Approve the production specification before using these figures on packaging, quotations or compliance documents.
Hot Tags: 20+2m wall mounted retractable garden hose reel with adjustable nozzle, China 20+2m wall mounted retractable garden hose reel with adjustable nozzle manufacturers, suppliers, factory
| Item | Reference Specification |
|---|---|
| Product type | Wall-mounted automatic retractable garden hose reel |
| Outlet hose length* | 20 m |
| Inlet hose length* | 2 m |
| Hose diameter* | 1/2 inch (approximately 12.5 mm) |
| Hose material* | PVC mesh garden hose |
| Housing material* | PP |
| Rewind system* | Automatic spring rewind with length locking |
| Bracket movement* | 180-degree swivel |
| Working / burst pressure* | 8 / 24 bar |
| Reference temperature range* | -5°C to 45°C |
| Approximate product dimensions* | 420 x 210 x 385 mm |
| Approximate net weight* | 7.8 kg |
| Nozzle | Adjustable straight nozzle; mist-to-jet control |
| Color shown | Grey and lime green |
| Reference packing* | 1 unit per color box |
*Verification notice: Starred values are inferred from comparable 20 m wall-mounted automatic hose reels. Confirm the exact production model through an approved sample, pressure test and supplier specification before publication as guaranteed data.
